158 Mono 330w Solar Panels


Solar Cell 158 Mono
Power 330W
Module Efficiency 20.28%
Voltage at Pmax(Vmp) 30V
Current at Pmax(Imp) 11.31A
Open Circuit Voltage(Voc) 35.83V
Short Circuit Current(Isc) 12.28A
Dimension 1640*992*35mm



Inquiry Now

To master the mystery of energy, choose monocrystalline solar panels! Its unique selling point lies in its high-efficiency conversion, fully converting sunlight into electrical energy; durable and reliable, long-term stable power generation; space-saving, compact design suitable for various scenarios. Monocrystalline solar panels create a reliable, efficient and energy-saving green energy future for you!


Mechanical Diagrams













Certification authority



Brand customization;


Batch No. Logo Parameter label Package


Product Features;

High conversion efficiency:

Monocrystalline solar panels are made from high-purity monocrystalline silicon, allowing them to efficiently convert solar energy into electricity, providing higher energy output.

Robust performance stability:

Monocrystalline solar panels undergo rigorous quality control and testing, ensuring excellent performance stability. They can operate reliably for long periods of time, unaffected by temperature and light fluctuations.

Durability and reliability:

Monocrystalline solar panels are tested for durability, exhibiting high durability and reliability. They can operate consistently over extended periods, reducing maintenance and replacement costs.

Wide adaptability:

Monocrystalline solar panels are suitable for various applications, including residential, commercial, and industrial sectors. Whether installed on rooftops or ground-mounted, they can meet diverse energy requirements.

Compact design:

 Monocrystalline solar panels feature a compact design, optimizing the use of installation space. This makes them suitable for installations in limited spaces and facilitates easy installation and arrangement.


Liectrical Parameters at (STC)   Mechanical Parameters
Power(W) 330W Solar Cell(Type/Size) Mono(158mm)
 Module Efficiency 20.28% Dimensions 1640*992*35mm
Voltage at Pmax(Vmp) 29.17V Weight KG
Current at Pmax(Imp) 11.31A Mechanical Load Front 5400Pa/Back 2400Pa
Open Circuit Voltage(Voc)
35.83V Cable Cross Section Size
100CM 4mm² solar cabel
Short Circuit Current(Isc) 12.28A Waterproof junction box IP67/QX-SY002 3*20A diode






Product Usage;

Residential installations:

Monocrystalline solar panels are commonly used on residential rooftops to generate electricity for household consumption. Residents can reduce their reliance on the traditional power grid and lower energy consumption costs by utilizing solar power systems.

Commercial and industrial sectors:

Monocrystalline solar panels are suitable for energy supply in commercial buildings and industrial facilities. For example, they can be installed on the roofs or ground of stores, office buildings, factories, and warehouses to provide renewable energy for commercial electricity and production processes.

Agriculture and rural areas:

Monocrystalline solar panels find extensive applications in the agricultural sector and rural areas. They can provide power for farms, greenhouses, water pump systems, etc., helping farmers achieve energy-saving and emissions reduction goals while improving agricultural productivity.

Remote areas and off-grid applications:

Monocrystalline solar panels are an ideal choice for remote areas without access to the traditional power grid or locations that require off-grid applications. They can provide reliable electricity supply for remote communities, campsites, and mobile communication base stations.


Installation case;


Power Station Outdoor RV Power Supply
