QN-158M01018

 Product Features;



◆High efficiency:

MBB technology is adopted to improve the photoelectric conversion efficiency and achieve higher power generation capacity.



◆Low resistance loss:

The design of multiple current collection lines reduces the flow distance of the current inside the cell and reduces resistance loss.



◆High Reliability:

By reducing the stress and thermal stress between cells, the reliability and long-term performance stability of the module are improved.



◆Beautiful appearance:

Modules using MBB technology have a more detailed cell layout and less wire shielding, presenting a more beautiful appearance.



◆Adapt to complex environments:

With good anti-PID performance and durable anti-reflection coating, it can work in different climates and environmental conditions, and has certain pressure and wind resistance.







  Products Description







Liectrical Parameters at （STC）		Mechanical Parameters
Power（W）	10W	Solar Cell（Type/Size）	Mono(158mm)
Module Efficiency（%）	11.31%	Solar Cells Number	36Pcs(2*18)
Voltage at Pmax（Vmp）	17.5V	Dimension	340*260*17mm
Current at Pmax（Imp）	0.57A	Weight	KG/Pcs
Open Circuit Voltage（Voc）	21.5V	Junction Box	IP67/0*bypass diode
Open Circuit Voltage（Voc）	0.62A	Cable	//
Power Tolerance（W）	±3%	Connector	//
PS; If you have special requirements, you can contact customer service for customization.









  Product Packaging

Product Barcode	Brand Logo
Parameter Label	Package





Packing
Carton Size	655*375*185mm	Number	5Pcs/Ctn
Weight	KG/Ctn	20GP Container	4070 Pcs
Volume	0.034Cbm/Ctn	40HQ Container	10175 Pcs
Customizable: LOGO, parameter label, product batch number, packaging
